CDA70 MODEM DESCRIPTION
21
Connection of the jumpers:
• Ethernet
Port ETH
Power supply Internal ...
Environment
Operating temperature -20 .. +55 C
Storage temperature -20 .. +85 C
Standards
Emission EN 55022/B
Immunity ETS 300 342
Safety EN 60950
Ethernet specification Max. virtual communicate
channels number
6
Max. bit rate 100 Mbps
Max. total cable length
(300Bd, 200nF/km)
100 m
CDA-70-U(V)-EM version
Jumpers SK9 a SK10
CDA-70-U(V)-4M version
Jumper J4
