CONEL CDA 70 [4/43] Safety instructions
![CONEL CDA 70 [4/43] Safety instructions](/views2/1190531/page4/bg4.png)
SAFETY INSTRUCTIONS
4
1. Safety instructions
Please observe the following safety instructions:
• The communication module has to be used in accordance with all applicable international
and national laws or any special regulations that may govern its use for particular
applications and devices.
• Use only the original Conel company accessories. Thus you will prevent possible health
risks and damage to the devices and ensure compliance with all relevant provisions.
Unauthorised adjustments or use of unapproved accessories may result in damage to the
module and breach of applicable laws. Use of unapproved adjustments or accessories
may lead to cancellation of guarantee, which has no effects on your legal rights.
• Voltage on the communication module supply connector shall not be exceeded.
• Do not expose the communication module to extreme conditions. Protect it from dust,
moisture and heat.
• It is recommended not to use the communication module at petrol stations. We remind
users to observe the limitations of radio devices use at pump stations, chemical plants or
where explosives are being used.
• You have to be extremely careful when using the communication module in proximity to
medical devices, such as pacemakers or hearing aids.
• It is recommended to create a proper copy or backup of all the important settings saved
in the device's memory, to database by help program Radwin, reference [1].
