CDA70 MODEM DESCRIPTION
8
2.3.6. Technical parameters
Frequency band 143 – 174 MHz (CDA70V version)
403 – 470 MHz (CDA70U version)
Adjustment of working frequency program setting
Adjustment of working frequency of
receiver and transmitter
separate for each part
Adjustment of channel spacing program setting
12,5; 25 kHz (CDA70V version)
12,5; 20; 25 kHz (CDA70U version)
Output power program setting
0.5;1;2;3 W (CDA70V version)
0,01;0,05;0,1;0,25;0,5;1;2;3;4;5 W (CDA70U
version)
Receiver sensitivity for 10 dB SINAD <-111 dBm (12 dB SINAD) for channel 25/20 kHz
<-117 dBm (12 dB SINAD) for channel 12,5 kHz
Reception / transmission switching time < 4 msec
Maximum transmission rate 21.7 kbit/sec for channel spacing of 20 and 25 kHz
10.8 kbit/sec for channel spacing of 12.5 kHz
Type of modulation 4-FSK, GMSK
Radio modem
complies with
standards:
Radio parameters
EMC
Power safety
EN 300 113-1: V1.5.1
EN 300 113-2: V1.2.1
EN 301 489-5: V1.3.1
EN 60 950-1:2001
Temperature range Operation
Storage
-20 °C to +55 °C
-40 °C to +85 °C
Supply voltage (car dashboard) +10.8 to +15.6V DC
Current Reception
Transmission 1 W
Transmission 5 W
<200 mA
<900 mA
<1500 mA
Dimensions 43x104x98 mm (DIN35 attachment to board)
Weight 600g
Antenna connector BNC – 50 Ohm
User interface PORT1
PORT2
PORT3
ETHERNET
I/O
See. chapter 2.5.1
See. chapter 2.5.2
See. chapter 2.5.3
See. chapter 2.5.4
See. chapter 2.5.5
