CDA70 MODEM DESCRIPTION
7
outputs. With the equipment you may establish simple telemetry at low cost, without the use
of industrial control automat.
2.3.5.
User interface protocols
For user interface, a range of standard protocols is implemented:
• AT modem
• PROFIBUS
• M-BUS
• MODBUS
• Asynchronous transparent line
• Transparent bus
• Sauter
• IWKA
• SBUS
• RADOM
• RDS
New protocols, currently not supported by the radio modem, can be implemented
according to the customer's needs.
