TD-W8901N
150Mbps Wireless N ADSL2+ Modem Router User Guide
Step 2: Connect the Ethernet cable. Attach one end of a network cable to your computer’s
Ethernet port or a regular hub/switch port, and the other end to the LAN port on the
TD-W8901N.
Step 3: Power on the computers and LAN devices.
Step 4: Attach the power adapter. Connect the power adapter to the power connector on the rear
of the device and plug in the adapter to an electrical outlet or power extension. The
electrical outlet shall be installed near the device and shall be easily accessible.
Ethernet Cable
Computer
Phone Cable
PHONE
MODEM
LINE
Splitter
Phone Cable
Wall Socket
POWER ON/OFF
WPS/
RESET
WiFi
LAN4
LAN3
LAN2
LAN1
ADSL
Figure 2-4
8
