USING THE PEN BUTTONS
The Bamboo One pen has two buttons. Each button has a programmable function that is selected when you
press the button. You can use a pen button whenever the pen tip is within 5 mm (0.20 inch) of the tablet
active area. You do not have to touch the pen tip to the tablet in order to use a button.
To assign new button functions, see customizing the pen b
uttons.
Hint: Set a pen button to DOUBLE
CLICK. This is easier than tapping
twice with the pen tip.
The upper pen button is set to RIGHT CLICK, and the lower button
is set to PAN/SCROLL by default.
• Use RIGHT CLICK to bring up application-specific or icon-
specific menus.
•PAN/SCROLL lets you position a document or image in any
direction within the active window by pressing the pen
button and moving the pen tip across the tablet’s active area.
As you move the pen tip, the document or image is
repositioned to follow the direction of pen movement on the
tablet. Release the pen button or lift the pen tip from the
tablet surface when you are done.
In some application windows the document will precisely
follow the screen cursor as you move the pen tip, while in
others it will simply move in the same general direction as
the screen cursor.
Example of pan/scroll movement
on computer display.
Example of right click on
computer display.
