WORKING WITH THE TABLET

The middle area of the tablet is the working, or active, area for the pen. Rest your hand on the tablet and

then work with the pen on the active area of the tablet just as if you were using a ball point pen on a piece of

paper. Wherever you place your pen on the tablet active area, the screen cursor will jump to the

corresponding point on the screen. See using the cordless pen

for more information.
