TABLET TRACKING
The tablet TRACKING options enable you to define the relationship between pen movement on the tablet
surface and cursor movement on the monitor screen. By default the entire active area of the tablet maps to
the entire monitor. If more than one monitor is in use the tablet will map to all monitors. See mapping to
multiple monitors.
The TRACKING mode you select
controls how the screen cursor
moves:
• Select P
EN MODE to set the
cursor so that its movement
corresponds with the position of
your Bamboo One pen on the
tablet – wherever you place
your pen on the tablet, the
cursor will jump to a
corresponding point on the
screen. This is known as
absolute positioning, and is the
default setting for the Bamboo
One pen. Click DETAILS... to
customize the tablet mapping.
• Select MOUSE MODE to move
the screen cursor with a “pick
up and slide” motion similar to
using a traditional mouse.
Click DETAILS... for setting
mouse speed.
Note: If you frequently switch between
PEN MODE and MOUSE MODE, you can
assign the MODE TOGGLE... function to
one of your pen buttons.
