• PAN/SCROLL. Lets you position a document or image in any direction within the active pane by pressing
a pen button set for P
AN/SCROLL and then moving the pen tip across the tablet’s active area.
• K
EYSTROKE.... Enables you to simulate keystrokes. Selecting this option displays the DEFINE
K
EYSTROKE dialog box where you can enter a keystroke or keystroke sequence to play back.
When you select PAN/SCROLL, the PEN SCROLLING
SPEED dialog box prompts you to set a scrolling
speed that will be used in applications that do not
support grabber hand (pixel-level) panning within
a document or image.
A slower setting reduces the scroll rate and is
useful for close-up and detail work where you
need precise control of the image.
You can manually enter a keystroke or keystroke
combination in the KEYS entry box.
Keystroke combinations can include letters,
numbers, function keys (such as F3) and modifier
keys (such as S
HIFT, ALT, or CTRL for Windows, or
SHIFT, OPTION, COMMAND, and CONTROL for
Macintosh).
You can also select special keystrokes or
keystroke combinations from the ADD SPECIAL
drop-down menu.
After defining a keystroke sequence, click OK.
Important: Because the ENTER
(Windows) and RETURN (Macintosh)
keys can be selected as a defined
keystroke, it cannot be used to select OK.
You must use your Bamboo One pen to
click on the OK button.
If prompted, enter a name for the keystroke
definition. The name will be displayed with the
respective control.
Clears the keystroke entry box.
Deletes only the last entry in the
keystroke entry box.
