MAPPING TO MULTIPLE MONITORS
If your computer has more than one monitor, Bamboo One will map to your monitors based upon how they
are configured in the
DISPLAY PROPERTIES control panel. If ALL SCREENS is selected and you are in extended
monitor mode, the tablet will map to all monitors as if they were one large display. If the monitors are in
mirror mode, the tablet will map to the entire space on each monitor and the screen cursor will be displayed
on each monitor simultaneously.
See your hardware and operating system documentation for details on configuring your computer and
operating system for use with multiple monitors.
PORTION OF SCREEN AREA
The tracking options in the PEN MODE DETAILS dialog box allow you to define which portion of the display
screen your tablet will map to:
• A
LL SCREENS. Maps the entire monitor(s) area. This is the default setting.
• MONITOR. Maps the entire area of a single monitor that you choose.
• PORTION. Allows you to select a portion of the display for tablet to screen mapping. Click SET... to open
the P
ORTION OF SCREEN dialog box.
Choose a method for defining a
portion of the display:
• Drag corners of the foreground
graphic to select the screen area.
• Move the screen cursor to select
the screen area. Select the CLICK
TO DEFINE SCREEN AREA button.
As you define PORTION OF
SCREEN, follow any MESSAGE
prompts to set the portion of your
display screen that will be used for
mapping.
After defining a portion of the screen,
you may need to use a different input
device to access other portions of the
screen area.
