![Yealink SIP-T19 E2 [398/841] Procedure](/views2/1192075/page398/bg18e.png)
Administrator’s Guide for SIP-T2 Series/T19(P) E2/T4 Series IP Phones
382
Parameter
Permitted Values
Default
Description:
It configures the duration time (in seconds) in the ringing state.
If it is set to 180, the phone will stop ringing if the call is not answered within 180s.
Web User Interface:
None
Phone User Interface:
None
When placing a call, the IP phone will send an INVITE request to the proxy server. Send
user=phone feature allows adding user=phone to the SIP header of the INVITE
message.
Example of a SIP INVITE message:
INVITE sip:101@10.3.5.199:5060;user=phone SIP/2.0
Via: SIP/2.0/UDP 10.3.20.6:5060;branch=z9hG4bK2475812834
From: "1010" <sip:1010@10.3.5.199:5060>;tag=3747068208
To: <sip:101@10.3.5.199:5060;user=phone>
Call-ID: 0_4008470062@10.3.20.6
CSeq: 1 INVITE
Contact: <sip:1010@10.3.20.6:5060>
Content-Type: application/sdp
Allow: INVITE, INFO, PRACK, ACK, BYE, CANCEL, OPTIONS, NOTIFY, REGISTER, SUBSCRIBE, REFER,
PUBLISH, UPDATE, MESSAGE
Max-Forwards: 70
User-Agent: Yealink SIP-T23G 44.80.0.20
Allow-Events: talk,hold,conference,refer,check-sync
Content-Length: 300
Procedure
Send user=phone can be configured using the configuration files or locally.
Configuration File
<MAC>.cfg
Configure send user=phone
feature on a per-line basis.
Parameters:
account.X.enable_user_equal_ph
one
