Administrator’s Guide for SIP-T2 Series/T19(P) E2/T4 Series IP Phones
408
Abbreviation
Name
Description
-
telephoneNumber
Office phone number
mobile
mobilephoneNumber
Mobile or cellular phone number
ipPhone
IPphoneNumber
Home phone number
For more information on LDAP, refer to
LDAP Phonebook on Yealink IP Phones
.
Procedure
LDAP can be configured using the configuration files or locally.
Configuration File
<y0000000000xx>.cfg
Configure LDAP.
Parameters:
ldap.enable
ldap.name_filter
ldap.number_filter
ldap.tls_mode
ldap.host
ldap.port
ldap.base
ldap.user
ldap.password
ldap.max_hits
ldap.name_attr
ldap.numb_attr
ldap.display_name
ldap.version
ldap.call_in_lookup
ldap.call_out_lookup
ldap.ldap_sort
ldap.incoming_call_special_sear
ch.enable
Assign an LDAP key.
Parameters:
linekey.X.type/
programablekey.X.type/
expansion_module.X.key.Y.type
linekey.X.label/
programablekey.X.label/
expansion_module.X.key.Y.label
