Administrator’s Guide for SIP-T2 Series/T19(P) E2/T4 Series IP Phones

566

A dialog box pops up to prompt that settings will take effect after a reboot.

5. Click OK to reboot the phone.

To configure CDP feature via phone user interface:

1. Press Menu->Settings->Advanced Settings (default password: admin)

->Network->CDP->CDP Status.

2. Press or , or the Switch soft key to select the desired value from the CDP

Status field.

3. Enter the priority value (1-3600s) in the Packet Interval field.

4. Press the Save soft key to accept the change.

The IP phone reboots automatically to make settings effective after a period of time.

VLAN is disabled on IP phones by default. You can configure VLAN for the Internet port

and PC port manually. Before configuring VLAN on the IP phone, you need to obtain the

VLAN ID from your network administrator.

Procedure

VLAN can be configured using the configuration files or locally.

Configuration

File

<y0000000000xx>.cfg

Configure VLAN for the Internet port

and PC port manually.

Parameters:

network.vlan.internet_port_enable

network.vlan.internet_port_vid

network.vlan.internet_port_priority

network.vlan.pc_port_enable

network.vlan.pc_port_vid

network.vlan.pc_port_priority

Local

Web User Interface

Configure VLAN for the Internet port

and PC port manually.

Navigate to:

http://<phoneIPAddress>/servlet?p=n

etwork-adv&q=load

Phone User Interface

Configure VLAN for the Internet port

and PC port manually.
