Configuring Advanced Features

423

pick up the monitored user’s incoming call by pressing the DPickup soft key. The

directed call pickup code must be configured in advance. For more information on how

to configure the directed call pickup code for the Pickup soft key, refer to Directed Call

Pickup on page 315.

BLF LED Mode

BLF LED Mode provides four kinds of definition for the BLF/BLF List key LED status. As

there is no hard line key on SIP-T48G IP phones, BLF LED mode configuration is only

applicable to SIP-T46G/T42G/T41P/T29G/T27P/T23P/T23G/T21(P) E2 IP phones. BLF LED

mode is also applicable to the expansion module EXP40 connected to SIP-T48G/T46G IP

phones, EXP38/EXP39 connected to SIP-T29G and SIP-T27P IP phones. The following table

lists the LED statuses of the BLF key when BLF LED Mode is set to 0, 1, 2 or 3 respectively.

The default value of BLF LED mode is 0.

BLF LED mode feature is also applicable to BLF list key. For more information on BLF List

key, refer to BLF List on page 433.

Line key/Expansion Module Key LED (configured as a BLF key or a BLF List key and BLF

LED Mode is set to 0)

LED Status

Description

Solid green

The monitored user is idle.

Fast flashing red (200ms)

The monitored user receives an incoming call.

Solid red

The monitored user is dialing.

The monitored user is talking.

The monitored user’s conversation is placed on hold

(This LED status requires server support).

Slow flashing red (1s)

The call is parked against the monitored user’s phone

number.

Off

The monitored user does not exist.

Line Key/Expansion Module Key LED (configured as a BLF key or a BLF List key and BLF

LED Mode is set to 1)
