Zotac zbox-ci321nano-be [19/20] Configuring audio output via an hdmi device

ZOTAC ZBOX nano

Using a dynamic IP (PPPoE connection)

1. Repeat Step 1-3 in the previous section.

2. Select “Obtain an IP address automatically” and click “OK”.

3. Click “Create a new connection” to start the NEW Connection Wizard.

4. Click “Next”.

5. Select “Connect to the Internet” and click “Next”.

6. Select “Set up my

connection manually”.

7. Select your connection

type and click “Next”.

8. Enter your ISP Name and

click “Next”.

9. Enter your User name and

Password. Click “Next”.

10. Click “Finish” to nish the

conguration.

11. Enter your user name and password. Click

“Connect” to connect to the internet.

Note: Contact your internet Service Provider (ISP) if you have problems connecting to the network.

Conguring audio output via an HDMI device

Follow the steps below to enable audio output via HDMI when connecting the

ZOTAC ZBOX nano to a TV or receiver via HDMI.

1. Access the Sound settings via the system

Control Panel.

2. Under Playback devices, click the display

device that corresponds with your HDMI

audio compatible display

3. Click the “Set Default” button in the lower

right hand corner.

4. Click “OK” to exit the setup.
