Zotac zbox-bi319-e [14/16] Installing drivers and software

ZOTAC ZBOX

Installing drivers and software

Installing an operating system

The ZOTAC ZBOX does not ship with an operating system preinstalled. The user

must install the operating system before the ZOTAC ZBOX can be used. The

following operating systems are supported:

• Windows 7

• Windows 8

Follow the instructions below to install an operating system:

1. Attach external DVD drive via USB port.

2. Insert disk for operating system (Windows or Linux).

3. Wait for the ZOTAC ZBOX to boot from the disk.

4. Follow the onscreen directions to install the operating system.

5. Install system drivers to gain full functionality of the ZOTAC ZBOX hardware and

features.

Note: For best compatibility, please only use the USB 2.0 ports as the OS

installation source drive connection.

Installing system drivers

Before you can use the full features of the ZOTAC ZBOX, the system drivers must

be installed. The following types of operating systems are supported by the ZOTAC

ZBOX driver DVD:

• Windows 7

• Windows 8

Follow the instructions below to install the system drivers:

1. Insert the ZOTAC ZBOX driver DVD. If autorun is enabled, the driver installation

main menu will show up automatically. If autorun is disabled, you may click the

le Launch.EXE to bring up the driver installation main menu.

2. The following drivers are available on the DVD:

• Intel Chipset Driver

• HDA Sound Driver

• Intel Graphics Driver

• Ethernet PCI-E Driver

• USB3.0 Controller Driver

• Intel Management Engine

• MassStorage Driver

• USB Charger (optional)
