Installation
16 312394W
Auto-Refill Installation
The Auto-Refill assembly is shipped uninstalled. The
Auto-Refill assembly can be installed in multiple places
on the tanks. See FIG.5.
Pressure Transducer and Flow
Meter Installation
See manual 312760.
FIG. 5: Auto-Refill Installation Locations
ti12393a
1
Possible locations for Auto-Refill installation.
1
1
