Graco PR70 [26/74] Agitator fuse replacement
![Graco PR70 [26/74] Agitator fuse replacement](/views2/1192945/page26/bg1a.png)
Repair
26 312394W
Agitator Fuse Replacement
1. Slide open the fuse drawer (706).
2. Remove old fuse (707) and replace with new fuse.
706
707
ti12559a
