Parts
66 312394W
Level Sensors
Polyethylene Tanks Level Sensors,
Assembly LC0278
2001
2003
2002
ti12470b
Ref Part Description Qty
2001 123549 SENSOR, level, quick disconnect 2
2002 121686 CABLE, M8 x M8, 4P, female / male,
straight/right angle, 2 m
2
2003 96/1000/99 FASTENER, screw, socket head cap,
M3 x 8, mild steel
4
