Pioneer DJM-500 [10/20] Assign switch assign a b
![Pioneer DJM-500 [10/20] Assign switch assign a b](/views2/1019354/page10/bga.png)
10
<DRB1192>
NAME AND FUNCTION OF PARTS
9 Monitor Monaural/Stereo Selector Switch
(MONO/STEREO)
0 Monitor Equalizer Knob (MONITOR EQ)
Used to obtain the beat easily with the headphone moni-
tor sound.
Increases/decreases low tone.
Flat at center click.
Increases when rotated to the right. (To +12 dB at 100 Hz)
Decreases when rotated to the left. (To –12 dB at 100 Hz)
- Monitor Level Knob (MONITOR LEVEL)
Used for adjusting the headphone monitor volume.
Not affected by the master volume and master balance.
= Headphone Terminal (PHONES)
~ Channel Fader Volume
Used for adjusting the volume of CH1 to CH4.
! Assign Switch (ASSIGN A, B)
When performing cross fader using two sources (A, B),
select the channels (CH1 to CH4) to be assigned to A
and B.
Effective when the cross fader switch ($) is on (cross
fader mix).
@ Fader Start Switch (FADER START) (Refer to
Page 17.)
When the optional CD player (CDJ-500G or CDJ-500 )
is connected to the unit using the control cord, this
ON/OFF switch is used to start automatic playing of
the CD player using the channel fader or cross fader.
# Cross Fader Volume (CROSS FADER)
Adjusts the mix volume of the sources set to A and B
using the assign switch (!).
$ Cross Fader Switch (CROSS FADER ON/OFF)
OFF:
Select when mixing sounds using the channel fader volume.
(Direct mix.)
ON:
Select when mixing sounds using the cross fader. (Cross
fader mix.)
% Master Volume Level Adjustment
Used to adjust the level of the master output volume.
When the cross fader is ON, the sounds of assigns A, B
and main microphone will be output.
When the cross fader is OFF, the sounds of each channel
and main microphone will be output.
^ Master Balance Knob (MASTER BALANCE)
Used to adjust the left and right balance of the master
output.
& Booth Monitor Level Knob (BOOTH MONITOR
LEVEL)
Used to adjust the output level of the BOOTH MONITOR
terminal.
Not affected by the master volume and master balance.
* Effect Selector Switch (EFFECT SELECTOR)
AUTO BPM (Beat/minute):
Select when performing BPM detection.
DELAY:
Delays the time and repeats once.
ECHO:
Delays the time and repeats several times to produce the
echo effects.
AUTO PAN:
Shifts the left and right channels periodically.
FLANGER:
Produces periodic sound change effects by mixing the
short delay sound and original sound.
REVERB:
Produces the reverb effects.
PITCH SHIFTER:
Changes the pitch of the song.
SEND/RETURN:
Select when connecting and using the external effector.
( Effect Channel Selector (CH. SELECTOR)
Use to select the source to be effected.
) Parameter Knob (PARAMETER)
Used to adjust the parameter of the effector selected with
the effect selector switch.
DELAY:
0 to 680 mSec (2 mSec step to 100, 5 mSec step from 100
to 680)
ECHO:
0 to 680 mSec (2 mSec step to 100, 5 mSec step from 100
to 680)
AUTO PAN:
0 to 3500 mSec (5 mSec to 100, 10 mSec from 100 to 900,
20 mSec step from 900 to 3500)
FLANGER:
100 to 9000 mSec (10 mSec to 900, 50 mSec from 900
to 9000)
REVERB:
0 to 100% (1% step)
PITCH SHIFTER:
0 to ±100% (1% from 0 to 10, 2% step from 10 to 100)
_ Effect Switch (EFFECT ON/OFF)
Use to switch the effect on/off.
When turned on according to the beat, the effects will
also correspond to the beat.
When the effect is on, it goes on and off.
