![Pioneer DJM-500 [2/20] Safety instructions](/views2/1019354/page2/bg2.png)
2
<DRB1192>
The lightning flash with arrowhead, within an equilateral
triangle, is intended to alert the user to the presence of
uninsulated "dangerous voltage" within the product's
enclosure that may be of sufficient magnitude to
constitute a risk of electric shock to persons.
CAUTION
IMPORTANT
CAUTION:
TO PREVENT THE RISK OF ELECTRIC SHOCK, DO NOT
REMOVE COVER (OR BACK). NO USER-SERVICEABLE
PARTS INSIDE. REFER SERVICING TO QUALIFIED
SERVICE PERSONNEL.
The exclamation point within an equilateral triangle is
intended to alert the user to the presence of important
operating and maintenance (servicing) instructions in the
literature accompanying the appliance.
READ INSTRUCTIONS – All the safety and operating
instructions should be read before the appliance is
operated.
RETAIN INSTRUCTIONS – The safety and operating
instructions should be retained for future
reference.
HEED WARNING – All warnings on the appliance and
in the operating instructions should be adhered to.
FOLLOW INSTRUCTIONS – All operating and use in-
structions should be followed.
WATER AND MOISTURE – The appliance should not
be used near water – for example, near a bathtub,
washbowl, kitchen sink, laundry tub, in a wet
basement, or near a swimming pool, etc.
LOCATION – The appliance should be installed in a
stable location.
WALL OR CEILING MOUNTING – The appliance
should not be mounted to a wall or ceiling.
VENTILATION – The appliance should be situated so
that its location or position does not interfere with
its proper ventilation. For example, the appliance
should not be situated on a bed, sofa, rug, or
similar surface that may block the ventilation
openings; or, placed in a built-in installation, such
as a bookcase or cabinet that may impede the
flow of air through the ventilation openings.
HEAT – The appliance should be situated away from
heat sources such as radiators, heat registers,
stoves, or other appliances (including amplifiers)
that produce heat.
POWER SOURCES – The appliance should be con-
nected to a power supply only of the type de-
scribed in the operating instructions or as marked
on the appliance.
POWER-CORD PROTECTION – Power-supply cords
should be routed so that they are not likely to be
walked on or pinched by items placed upon or
against them. Pay particular attention to cords at
plugs, convenience receptacles, and the point
where they exit from the appliance.
GROUNDING-TYPE PLUG – This product is equipped
with a three-wire grounding-type plug, a plug
having a third (grounding) pin.
This plug will only fit into a grounding-type power
outlet. This is a safety feature. If you are unable to
insert the plug into the outlet, contact your
electrician to replace your obsolete outlet. Do not
defeat the safety purpose of the grounding-type
plug.
CLEANING – The appliance should be cleaned only
with a polishing cloth or a soft dry cloth. Never
clean with furniture wax, benzine, insecticides or
other volatile liquids since they may corrode the
cabinet.
OUTDOOR ANTENNA GROUNDING – If an outside
antenna is connected to the antenna terminal, be
sure the antenna system is grounded so as to
provide some protection against voltage surges
and built-up static charges.
In the U.S.A. section 810 of the National Electrical
Code, ANSI/NFPA 70, provides information with
respect to proper grounding of the mast and
supporting structure, grounding of the lead-in wire
to an antenna discharge unit, size of grounding
conductors, location of antenna discharge unit,
connection to grounding electrodes, and
requirements for the grounding electrode. See
Fig. A.
CART – An appliance and cart combination should be
moved with care. Quick stops, excessive force,
and uneven surfaces may cause the appliance and
cart combination to overturn.
POWER LINES – An outdoor antenna should be located
away from power lines.
NONUSE PERIODS – The power cord of the appliance
should be unplugged from the outlet when left un-
used for a long period of time.
OBJECT AND LIQUID ENTRY – Care should be taken
so that objects do not fall and liquids are not spilled
into the enclosure through openings.
DAMAGE REQUIRING SERVICE – The appliance
should be serviced by a Pioneer authorized service
center or qualified service personnel when:
÷ The power-supply cord or the plug has been
damaged.
÷ Objects have fallen, or liquid has been spilled into
the appliance.
÷ The appliance has been exposed to rain.
÷ The appliance does not appear to operate normally
or exhibits a marked change in performance.
÷ The appliance has been dropped or the enclosure
damaged.
SERVICING – The user should not attempt to service
the appliance beyond that described in the
operating instructions. All other servicing should
be referred to qualified service personnel.
SAFETY INSTRUCTIONS
ANTENNA
LEAD IN
WIRE
GROUND
CLAMP
ANTENNA
DISCHARGE UNIT
(NEC SECTION 810 – 20)
GROUNDING CONDUCTORS
(NEC SECTION 810 – 21)
GROUND CLAMPS
POWER SERVICE GROUNDING
ELECTRODE SYSTEM
(NEC ART 250, PART H)
ELECTRIC
SERVICE
EQUIPMENT
FIG. A
NEC – NATIONAL ELECTRIC CODE
RISK OF ELECTRIC SHOCK
DO NOT OPEN
[For Canadian model]
This Class B digital apparatus meets all requirements of the Canadian Interference-Causing Equipment Regulations.
[Pour le modèle Canadien]
Cet appareil numerique de la Classe B respecte toutes les exigences du Reglement sur le material brouilleur du Canada.
Information to User
Alteration or modifications carried out without appropriate authorization may invalidate the user's right to operate the
equipment.
