Graco CycleFlo [17/18] Mounting information
![Graco CycleFlo [17/18] Mounting information](/views2/1193691/page17/bg11.png)
309003 17
Specifications
Power Requirements:
100–240 VAC, 50/60 Hz, 750 mA
Air Supply:
120 psi (0.8 MPa, 8 bar) Maximum
Mounting Information
9438A
5 in.
(127 mm)
8 7/8 in.
(225 mm)
