Technical Data
12 3A1189G
Bracket (2) Kits
2 - Bracket 24F870: Models 24F531 / 24F878 2 - Bracket 24F679: Model 24F947 / 24M499
Technical Data
2a SCREW, cap, hex head (not shown) 4
2b SCREW, cap, hex head 4
2c WASHER (not shown) 4
2d WASHER, plain 14
2e NUT, hex 7
2f PLATE, pump mount 1
2g HOLDER, nozzle bath 1
2h BRACKET, nozzle holder 1
2j SCREW, HH, 1/4 x 20 x 0.75” (not
shown)
3
2a SCREW, cap, hex head 4
2b SCREW, thumb, 1/4-20 x 2” 2
2d WASHER, plain 12
2e NUT, hex 6
2f PLATE, pump mount 1
2g HOLDER, nozzle bath 1
2h BRACKET, nozzle holder 1
2j SCREW, HH, 1/4 x 20 x 0.75” (not
shown)
2
Pump
US Metric
Maximum fluid working pressure 50 psi 0.3 MPA, 3.4 bar
Air pressure operating range 30 to 50 psi 0.2 to 0.3 MPA, 2.1 to 3.4 bar
Operating temperature (based on mechanical stress only and may be altered significantly by pumping certain chemicals.
Consult engineering guides for chemical compatibilities and temperature limits or contact your Graco distributor.
Minimum 40°F 4.4°C
Maximum 88°F 31.0°C
Maximum air consumption 28 scfm 0.672 cubic meters/min.
Maximum free flow delivery 6.5 gpm 25 lpm
Maximum pump speed 163 cpm
Gallons (Liters) per cycle 0.04 gallons 0.15 liters
Sound power level (measured per ISO standard 9614-2)
At 70 psig (0.48 MPa, 4.8 bar) at 50
cycles per minute
77 dBa
At 100 psig (0.7 MPa, 4 bar) at maximum
cycles per minute
95 dBa
Sound pressure level (measured 1 meter from pump)
At 70 psig (0.48 MPa, 4.8 bar) at 50
cycles per minute
67 dBa
At 100 psig (0.7 MPa, 4 bar) at maximum
cycles per minute
85 dBa
Air inlet size 1/4 npt(f)
Air exhaust port size 3/8 npt(f)
Fluid inlet size 1/2 and 3/4 in. bspp (f)
Fluid outlet size 1/2 and 3/4 in. bspp (f)
Wetted parts (in addition to ball, seat and dia-
phragm materials)
polypropylene, PTFE, fluoroelastomer, SST
Pump Weight (approximate) 6.5 lbs 2.9 kg
System Weight (approximate) 35 lbs 15.8 kg
