Graco 24F878 [13/14] Us metric

Technical Data

3A1189G 13

Meter

US Metric

Flow range 0.5 to 15 gpm 1.9 to 57 lpm

Maximum working pressure 50 psi 0.3 MPa, 3.4 bar

Minimum working pressure 5 psi 34 MPa, 0.3 bar

Weight 1.8 lb 0.82 kg

Unit of measurement (Display shows quantity

in 0.01 increments up to 999.99 gallons,

quarts, pints or liters. Totalizes in gallons or

liters up to 99,999 units.)

Factory-set in quarts

Accuracy (At 2.5 gpm (9.5 lpm) at 70°F (21°C),

with water and 1 gallon dispensed. May

require calibration; out-of-box accuracy is +/-

5%)

+/- 2.5% after calibration

Repeatability (At 2.5 gpm (9.5 lpm), at 70°F

(21°C), with water and 1 gallon dispensed.)

+/- 0.15%

Inlet and outlet 1/2 bspp

Operating temperature range -4°F to 122°F -25°C to 50°C

Storage temperature range -13°F ti 122°F -25°C to 50°C

Wetted parts SST, nickel, fluoroelastomer

Batteries (Recommended batteries: Dura-

cell

, Energizer

, Eveready

, EN22

)

2 AA Alkaline

Duracell

is a registered trademark of Duracell Inc.

Eveready

and Energizer

are registered trademarks of Eveready Battery Co., Inc.
