- 2 -
Overview
Moxa EtherDevice™ EDS-308/309 Series, which consists of 9-,and 8-port
smart Ethernet switches, provides an economical solution for your
Ethernet connections. As an added bonus, the built-in smart alarm
function helps system maintainers monitor the health of your Ethernet
network.
EDS-308/309 switches have a wide operating temperature range of -40
to 75°C, and are designed to withstand a high degree of vibration and
shock. The rugged hardware design makes EDS-308/309 Series perfect
for ensuring that your Ethernet equipment can withstand critical
industrial applications, and complies with FCC and CE Standards.
NOTE
Throughout this Hardware Installation Guide, we use EDS as an
abbreviation for Moxa EtherDevice Switch:
EDS = Moxa EtherDevice Switch
Package Checklist
Moxa EDS-308/309 is shipped with the following items. If any of these
items is missing or damaged, please contact your customer service
representative for assistance.
• Moxa EtherDevice™ Switch
• Hardware Installation Guide
• Moxa Product Warranty booklet
• Protective caps for unused ports
Features
High Performance Network Switching Technology
• 10/100BaseT(X) (RJ45), 100BaseFX (SC/ST-type, Multi/Single
mode)
• IEEE802.3/802.3u/802.3x
• Store and Forward switching process type, with 1024 address entries
• 10/100M, Full/Half-Duplex, MDI/MDIX auto-sensing
Industrial Grade Reliablity
• Power failure, port break alarm by relay output
• Redundant dual DC power inputs
Rugged Design
• Operating temperature range from 0 to 60°C, or extended operating
temperature from -40 to 75°C for “-T” models
• IP30, rugged high-strength case
• DIN-rail or panel mounting ability
WARNING
The
power for this product is intended to be supplied by a Listed
Power Supply, with output marked LPS, and rated to deliver 12 to
48 VDC at a maximum of 0.6A.
The DC
jack should be used with an LPS unit that is rated to
deliver 12 to 48 VDC at a minimum of 1.1A. The product should
not be disassembled by operators or service people.
