ATTENTION

This is a Class 1 Laser/LED product. To avoid

causing serious

damage to your eyes, do not stare directly into the Laser Beam.

Reset Button

The Reset Button supports two functions. One is to reset the Ethernet

switch to factory default settings by pressing and holding the Reset

button for 5 seconds. Use a pointed object, such as a straightened paper

clip or toothpick, to depress the Reset button. This will cause the STATE

LED to blink once a second. After depressing the button for 5 continuous

seconds, the STATE LED will start to blink rapidly, indicating that factory

default settings have been loaded and you can release the reset button.

When the ABC-02-USB is connected to the EDS-528E Ethernet switch, the

reset button allows quick configuration and backs up log files to the

ABC-02-USB. Press the Reset button on top of the EDS-528E; the

Ethernet switch will start backing up the current system configuration

files and event logs to the ABC-02-USB.

NOTE

Do NOT power off the Ethernet switch when loading default

settings.

Turbo Ring DIP Switch Settings

The EDS-528E switches are plug-and-play managed redundant Ethernet

switches. The proprietary Turbo Ring protocol was developed by Moxa to

provide better network reliability and faster recovery time. Moxa Turbo

Ring’s recovery time is less than 300 ms (Turbo Ring) or 20 ms (Turbo

Ring V2)—compared to a 3- to 5-minute recovery time for commercial

switches—decreasing the possible loss caused by network failures in an

industrial setting.

The 4 Hardware DIP Switches located on the top panel of the EDS-528E

can be used to easily configure Turbo Ring in only a few seconds. If you do

not want to use a hardware DIP switch to configure Turbo Ring, you can

use a web browser, Telnet, or serial console to disable the DIP switches.

NOTE

efer to the Turbo Ring section in the Communication

Redundancy

User’s Manual for detailed information about the

settings and usage of Turbo Ring and Turbo Ring V2.
