Installation in Brief 3
INSTALLATION IN BRIEF
We know you are eager to hear your new Fresco i
loudspeaker, so this section is provided to allow fast and
easy set up. Once you have it operational, please take
the time to read, in depth, the rest of the information in
this manual. It will give you perspective on how to attain
the greatest possible performance from this most exacting
transducer.
If you should experience any difficulties in the setup or
operation of your Fresco i speaker, please refer to the
Operation or Mounting sections of this manual.
Should you encounter a persistent problem that cannot
be resolved, please contact your authorized MartinLogan
dealer. They will provide you with the appropriate
technical analysis to alleviate the situation.
WARNING!
• Refer servicing to a qualified technician.
• To prevent fire or shock hazard, do not
expose this module to moisture.
• Turn amplifier off should any abnormal
conditions occur.
• Do not drive speaker beyond its rated power.
Step 1: Unpacking
Remove your new Fresco i speaker from the packing.
Step 2: Placement
Place the Fresco i near the desired location. Please see
the ‘Mounting the Fresco i On a Wall or Ceiling’ section
(page 5–12) for more placement details.
Step 3: Signal Connection
Use the best speaker cables you can. High quality cables,
available from your specialty dealer, are recommended
and will give you superior performance. Spade
connectors are suggested for optimum contact and ease
of installation.
Attach your speaker cables to the signal input section on
the rear panel. Be consistent when connecting speaker
leads to the terminals on the back of the Fresco i. Take
great care to assign the same color to the (+) terminal
on both the speaker and the amplifier. Please see the ‘
Operation’ section (page 4) for more details.
Step 4: Listen and Enjoy
Now, you may turn on your system and enjoy!
The lightning bolt flash with arrowhead symbol within
an equilateral triangle is intended to alert the user to
the presence of uninsulated “dangerous voltage" within
the product’s enclosure that may be of sufficient
magnitude to constitute a risk of electric shock.
The exclamation point within an equilateral triangle
is intended to alert the user to the presence of
important operating and maintenance (servicing)
instructions in the literature accompanying the
appliance.
