AWK-1121/1127 Web Console Configuration

3-28

Packet Length

Setting Description Factory Default

0 to 1024 This field specifies the maximum amount of data that is allowed

to accumulate in the serial port buffer before sending.

0: Packet length is disregarded and data in the buffer will be

sent as specified by the delimiter settings or when the buffer is

full.

1 to 1024: Data in the buffer will be sent as soon it reaches the

specified length.

Delimiter 1 and 2

Setting Description Factory Default

Enable When these fields are enabled, serial data will accumulate in

the serial port’s buffer until the buffer is full or until the

specified delimiter character(s) are received. For example, the

carriage return character could be used as a delimiter in order

to transmit each sentence or paragraph in a separate packet.

Data will be packed according to Delimiter process.

Delimiters must be incorporated into the data stream at the

software or device level.

The Delimiter value can be set ranging

from 00 to FF.

Unchecked

ATTENTION

When

Delimiter 1 is enabled, Packet length must be set to 0.

Delimiter Process

This field specifies how data is packed when delimiter characters are received. This field has no effect if

Delimiter 1 is not enabled.

Setting Description Factory Default

Do Nothing Data accumulated in the serial port’s buffer will be packed,

including delimiters.

Do Nothing

Delimiter + 1 One additional character must be received before the data in

the serial port’s buffer is packed.

Delimiter + 2 Two additional characters must be received before the data in

the serial port’s buffer is packed.

Strip Delimiter

Data accumulated in the serial port’s buffer will be packed, but

the delimiter character(s) will be stripped from the data.
