AWK-1121/1127 Introduction
1-4
Serial Port:
1, RS-232/422/485, DB9 male connector (AWK-1127 only)
Console:
RS-232 (RJ45-type)
LED Indicators:
PWR, FAULT, STATE, signal strength, WLAN, LAN
Weight:
400 g (AWK-1121), 410 g (AWK-1127)
Dimensions:
AWK
-1121: 50 x 115 x 70 mm (2.0 x 4.5 x 2.8 in)
AWK
-1127: 50 x 127 x 70 mm (2.0 x 5.0 x 2.8 in)
Installation:
DIN-Rail mounting, wall mounting (with optional kit)
Serial Communication Parameters
(AWK-1127 Only)
Data Bits:
5, 6, 7, 8
Stop Bits:
1, 1.5, 2
Parity:
None, Even, Odd, Space, Mark
Flow Control:
RTS/CTS, XON/XOFF
Baudrate:
50 bps to 921.6 Kbps
Serial Data Log:
256 KB
Serial Signals (AWK-1127 Only)
RS
-232: DSR, RTS, GND, TxD, RxD, DCD, CTS, DTR
RS
-422: Tx+, Tx-, Rx+, Rx-, GND
RS
-485 (2-wire): Data+, Data- and GND
RS
-485 (4-wire): Tx+, Rx+, Tx-, Rx+ and GND
Environmental Limits
Operating Temperature:
Standard Models: 0 to 60°C (32 to 140°F)
Wide Temp. Models:
-40 to 75°C (-40 to 167°F)
Storage Temperature:
-40 to 85°C (-40 to 185°F)
Ambient Relative Humidity:
5% to 95% (non-condensing)
Power Requirements
Input
Voltage: 12 to 48 VDC, redundant dual DC power inputs or 48 VDC Power-over-
Ethernet (IEEE 802.3af
compliant
, PoE model only)
Connector:
4-pin removable terminal block
Power Consumption:
•
0.16 to 0.55 A @ 12 to 48 VDC
• 0.
28 A @ 24 VDC
Reverse Polarity
Protection: Present
Regulatory Approvals
Safety:
EN60950-1, UL60950-1
Radio:
EN 300 328, EN 301 893, DSPR (Japan)
EMC:
EN 301 489-1/-17, FCC Part 15, EN 55022/55024
Note: Please check Moxa
’s website for the most up-to-date certification status.
Warranty
Warranty Period:
5 years
Details:
See www.moxa.com/warranty
ATTENTION
•
The AWK-
1121/1127 is NOT a portable mobile device and should be located at least 20 cm away from the
human body.
•
The AWK-1121/1127 is NOT designed for the general public. A well-
trained technician should be enlisted to
ensure safe deployment of AWK-1121/1127 units, and to establish a wireless network.
