AWK-1121/1127 Introduction
1-2
Overview
The AWK-1121/1127 Client is ideal for applications that are hard to wire, too expensive to wire, or use mobile
equipment that connects to a TCP/IP network. The AWK-1121/1127 can operate at temperatures ranging from
0 to 60°C for standard models and -40 to 75°C for wide temperature models, and is rugged enough for any
harsh industrial environment. Installation is easy, with either DIN-Rail mounting or wall mounting in
distribution boxes. The DIN-Rail/wall mounting capability, wide operating temperature range, and IP30
housing with LED indicators make the AWK-1121/1127 a convenient yet reliable solution for any industrial
wireless application.
Package Checklist
Moxa’s AWK-1121/1127 is shipped with the following items. If any of these items is missing or damaged,
please contact your customer service representative for assistance.
• AWK-1121/1127
• Swivel-type antenna (2dBi, RP-SMA, 2.4&5GHz)
• Quick Installation Guide
• Software CD
• Moxa Product Warranty Card
• Resistive terminator
• Protective cap
NOTE
The above items
come with the standard AWK-1121/1127 model, but the package contents may vary for
customized version
s.
Product Features
• IEEE802.11a/b/g compliant
• Dedicated client
• Advanced wireless security:
64-bit and 128-bit WEP/WPA/WPA2
SSID Hiding/IEEE 802.1X/RADIUS
Packet access control & filtering
• Turbo Roaming enables rapid handover (client based)
• ABC-01 for configuration import/export
• Dedicated antenna selection
• Free firmware update for more advanced functions
• RS-232 console management
• Wide -40 to 75°C operating temperature range (-T model)
• Redundant 24 VDC power inputs or IEEE802.3af Power over Ethernet (PoE model)
• DIN-Rail or wall mounting
• IP30 protected high-strength metal housing
