RS-232 Connection

The AWK-6222 has one RS-232 (8-pin RJ45) console port located on the

bottom panel. Use either an RJ45-to-DB9 or RJ45-to-DB25 cable to

connect the Moxa AWK-6222’s console port to your PC’s COM port. You

may then use a console terminal program to access the AWK-6222 for

console configuration.

Console Pinouts for 10-pin or 8-pin RJ45

10-Pin

Description

8-Pin

–

DSR

RTS

GND

TxD

RxD

DCD

CTS

DTR

–

NOTE

1. The pin numbers for male DB9 and DB25 male connectors,

and hole numbers for DB9 and DB25 female

connectors, are

labeled on the connector strip. However, the numbers are

typically quite small, so you may need to use a magnifying

glass to see the numbers clearly.

2. The pin numbers for both 8-pin and 10-

pin RJ45 connectors

(and ports) are typically not labeled on the connectors

(or

ports). Refer to the pinout diagram above for details.

ATTENTION

To ensure the IP6

8-rated connectivity, you must use a

waterproof housing during any communication activities. An

IP6

8-rated field installable plug, which is attached in AWK-

6222’s

accessory pack, may be needed in this case. The installation

instructions are shown below:
