- 12 -
LED Indicators
The front panel of the Moxa AWK-6222 contains several LED indicators.
The function of each LED is described in the table below:
LED
Color
State
Description
PWR Green
On
Power is being supplied (from power
input 1 or 2, or PoE)
Off
Power is not being supplied.
FAULT Red
On
The relay output is triggered by the
event.
Blinking
(slow at
1-second
intervals)
Cannot get an IP address from the
DHCP server.
Blinking
(fast at
0.5-second
intervals)
IP address conflict.
Off
No error condition exists.
STATE
Green/
Red
Green
System startup is complete and the
system is in operation.
Green
Blinking
(at 1-
second
intervals)
The device has been located by the
Wireless Search Utility.
Red
System is booting up.
WLAN 1
Green/
Amber
Green On
WLAN is functioning in client/slave
mode.
Green
Blinking
WLAN’s is transmitting data in
client/slave mode.
Amber On
WLAN is functioning in
AP/bridge/master mode.
Amber
Blinking
WLAN’s is transmitting data in
AP/bridge/master mode.
Off
WLAN is not in use or not working
properly.
WLAN 2
Green/
Amber
Green On
WLAN is functioning in client/slave
mode.
Green
Blinking
WLAN’s is transmitting data in
client/slave mode.
Amber On
WLAN is functioning in
AP/bridge/master mode.
Amber
Blinking
WLAN’s is transmitting data in
AP/bridge/master mode.
Off
WLAN is not in use or not working
properly.
LAN 1
Yellow/
Green
Yellow On
LAN port’s 10 Mbps link is active.
Yellow
Blinking
Data is being transmitted at 10 Mbps.
Yellow Off
LAN port’s 10 Mbps link is inactive.
Green On
LAN port’s 100 Mbps link is active.
Green
Blinking
Data is being transmitted at 100
Mbps.
Green Off
LAN port’s 100 Mbps link is inactive.
