PCI Express Boards Product Specifications

A-3

CP-168EL-A Specifications

Hardware

Connector SCSI VHDCI68

Comm. Controller 16C550C compatible

Interface

Bus Interface

PCI Express × 1

Number of Ports 8

Max No. of Boards 4 (only one IRQ required)

Signals

RS-232 TxD, RxD, RTS, CTS, DTR, DSR, DCD, GND

Performance

Baudrate 50 bps to 921.6 kbps

Configuration

Data Bits 5, 6, 7, 8

Stop Bits 1, 1.5, 2

I/O address/IRQ BIOS assigned

Parity None, Even, Odd, Space, Mark

Flow Control RTS/CTS, XON/XOFF

Power and Environment

Power Requirement 1225 mA (3.3V)

Operating Temperature 0 to 55°C (32 to 132°F)

Operating Humidity 5 to 95% RH

Storage Temperature -20 to 85°C (-4 to 185°F)

ESD Protection Embedded 15 kV ESD Protection

Standards and Certifications EN55022, EN55024, EN61000-3-2, EN61000-3-3, IEC 61000-4-2, IEC

61000-4-3, IEC 61000-4-4, IEC 61000-4-5, IEC 61000-4-6, IEC 61000-4-8,

IEC 61000-4-11 FCC Part 15 Class B

Warranty 5 years
