V2401/2402 Series Linux User’s Manual Managing Communications
3-8
Apache Web Server
Default Homepage
The Apache web server’s main configuration file is /etc/apache2/sites-enabled/000-default, with
the default homepage located at /var/www/apache2-default/index.html.
Save your own homepage to the following directory:
/var/www/apache2-default
Save your CGI page to the following directory:
/var/www/apache2-default/cgi-bin/
Before you modify the homepage, use a browser (such as Microsoft Internet Explore or Mozilla
Firefox) from your PC to test if the Apache web server is working. Type the LAN1 IP address in
the browser’s address box to open the homepage. For example, if the default IP address
192.168.3.127 is still active, type:
http://192.168.3.127/
To test the default CGI page, type:
http://192.168.3.127/cg
i-bin/w3mmail.cgi
Disabling the CGI Function
The CGI function is enabled by default. If you want to disable the function, modify the file
/etc/apache2/sites-enabled/000-default.
1. Mount the root file system with write permission.
2. Type # vi/etc/apache2/sites-enabled/000-default to edit the configuration file.
Comment on the following lines:
#ScriptAlias /cgi-bin/ /var/www/apache2-default/cgi-bin/
#<Directory "/var/www/apache2 default/cgi-bin/">
# AllowOverride None
# Options ExecCGI -MultiViews +SymLinksIfOwnerMatch
# #Order allow,deny
# Order deny,allow
# Allow from all
#</Directory>
MOXA:~# mount -o remount,rw /dev/
s
d
a
1
/
MOXA:/etc# vi /etc/apache2/sites-available/default
#ScriptAlias /cgi-bin/ /var/www/apache2-default/cgi-bin/
#<Directory "/var/www/apache2 default/cgi-bin/">
# AllowOverride None
# Options ExecCGI -MultiViews +SymLinksIFOwnerMatch
# #Order allow,deny
# Order deny,allow
# Allow from all
#</Directory>
