V2401/2402 Series Linux User’s Manual System Recovery
5-2
Recovery Environment
The recovery environment includes the V2401/2402-LX embedded computer and a bootable USB
disk with the recovery programs and system image file.
Recovery Procedure
Step 1: Format an Empty USB Disk.
a. Prepare a USB disk that has at least a 256 MB capacity.
b. Format your USB disk with the HP USB Disk Format Tool. Open the utility and select the
device and FAT file system. You need empty disk only. DO NOT check the option Create a
DOS startup disk.
c. Click Start.
Bootable USB DISK
(recovery programs and
system image file
included
)
V2401/2402-LX
USB Port
