V2401/2402 Series Linux User’s Manual Managing Communications
3-34
Ethernet Bridging for Private Networks on the Same Subnet
1. Set up four machines, as shown in the following diagram.
2. The configuration procedure is almost the same as for the previous example. The only
difference is that you will need to comment out the parameter up in /etc/openvpn/tap0-
br.conf of OpenVPN A and /etc/openvpn/tap0-br.conf of OpenVPN B.
# point to the peer
remote 192.168.8.174
dev tap0
secret /etc/openvpn/secrouter.key
cipher DES-EDE3-CBC
auth MD5
tun-mtu 1500
tun-mtu-extra 64
ping 40
#up /etc/openvpn/tap0-br.sh
#comp-lzo
