V2401/2402 Series Linux User’s Manual Managing Communications

3-33

9. On each OpenVPN machine, check the routing table by typing the command # route

Interface eth1 and device tap0 both connect to the bridging interface, and the virtual device

tun sits on top of tap0. This ensures that all traffic coming to this bridge from internal

networks connected to interface eth1 write to the TAP/TUN device that the OpenVPN

program monitors. Once the OpenVPN program detects traffic on the virtual device, it sends

the traffic to its peer.

10. To create an indirect connection to Host B from Host A, you need to add the following routing

item:

# route add –net 192.168.4.0 netmask 255.255.255.0 dev eth0

To create an indirect connection to Host A from Host B, you need to add the following routing

item:

# route add –net 192.168.2.0 netmask 255.255.255.0 dev eth0

Now ping Host B from Host A by typing:

# ping 192.168.4.174

A successful ping indicates that you have created a VPN system that only allows authorized

users from one internal network to access users at the remote site. For this system, all data is

transmitted by UDP packets on port 5000 between OpenVPN peers.

11. To shut down OpenVPN programs, type the command:

# killall -TERM openvpn

Destination Gateway Genmsk Flags Metric Ref

Use Iface

192.168.5.0 0.0.0.0 255.255.255.0 U 0 0 0

eth2

192.168.4.0 0.0.0.0 255.255.255.0 U 0 0 0

br0

192.168.3.0 0.0.0.0 255.255.255.0 U 0 0 0

eth0

192.168.30.0 0.0.0.0 255.255.255.0 U 0 0 0

eth3

192.168.8.0 0.0.0.0 255.255.255.0 U 0 0 0

br0
