V2401/2402 Series Linux User’s Manual Managing Communications

3-32

And then configure the bridge interface in /etc/openvpn/bridge.

Start the bridge script file to configure the bridge interface.

# /etc/openvpn/bridge restart

ATTENTION

Select cipher and authentication algorithms by specifying cipher and auth. To see which

algorithms are available, type:

# openvpn --show-ciphers

# openvpn --show-auths

8. Start both OpenVPN peers on machine OpenVPN A and OpenVPN B.

# openvpn --config /etc/openvpn/tap0-br.conf&

If you see the line Peer Connection Initiated with 192.168.8.173:5000on each machine, the

connection between OpenVPN machines has been established successfully on UDP port 5000.

ATTENTION

You can create link symbols to start the OpenVPN service at boot time:

# ln -sf /etc/init.d/openvpn /etc/rc2.d/S16openvpn

To stop the service, you should create these links:

# ln -sf /etc/init.d/openvpn /etc/rc0.d/K80openvpn

# ln -sf /etc/init.d/openvpn /etc/rc6.d/K80openvpn

#!/bin/bash

# Create global variables

# Define Bridge Interface

br="br0"

# Define list of TAP interfaces to be bridged,

# for example tap="tap0 tap1 tap2".

tap="tap0"

# Define physical ethernet interface to be bridged

# with TAP interface(s) above.

eth="eth1"

eth_ip="192.168.8.174"

eth_netmask="255.255.255.0"

eth_broadcast="192.168.8.255"

#gw="192.168.8.173"

...
