V2401/2402 Series Linux User’s Manual Managing Communications

3-31

And then configure the bridge interface in /etc/openvpn/bridge.

Start the bridge script file to configure the bridge interface.

# /etc/openvpn/bridge restart

6. On machine OpenVPN B, modify the remote address in configuration file

/etc/openvpn/tap0-br.conf.

7. Next modify the routing table in /etc/openvpn/tap0-br.sh script file.

#!/bin/bash

# Create global variables

# Define Bridge Interface

br="br0"

# Define list of TAP interfaces to be bridged,

# for example tap="tap0 tap1 tap2".

tap="tap0"

# Define physical ethernet interface to be bridged

# with TAP interface(s) above.

eth="eth1"

eth_ip="192.168.8.173"

eth_netmask="255.255.255.0"

eth_broadcast="192.168.8.255"

#gw="192.168.8.174"

...

# point to the peer

remote 192.168.8.173

dev tap0

secret /etc/openvpn/secrouter.key

cipher DES-EDE3-CBC

auth MD5

tun-mtu 1500

tun-mtu-extra 64

ping 40

up /etc/openvpn/tap0-br.sh

#comp-lzo

#----------------------------------Start---------------------

--------

#!/bin/sh

# value after “-net” is the subnet behind the remote peer

route add -net 192.168.2.0 netmask 255.255.255.0 dev br0

#---------------------------------- end ---------------------

--------
