V2401/2402 Series Linux User’s Manual System Recovery
5-3
ATTENTION
The HP USB Disk Storage Format Tool can be downloaded from many web sites. Do a search
on HP USB Disk Storage Format Tool from any search engine to locate the tool.
Step 2: Create a Linux Bootable USB Disk.
a. You can find the utility_tools\Recovery directory in the Recovery CD shipped with the
V2401/2402-LX computer.
b. Configure Windows Explorer to show hidden files (including protected operating system files).
c. Copy all files in the utility_tools\Recovery directory to the root directory of your USB disk.
d. Open a DOS prompt and type M:\syslinux.exe M: to create a bootable Linux disk.
In this example, M: is the USB Disk drive number.
