V2401/2402 Series Linux User’s Manual Managing Communications
3-21
Now, type:
#ping z.z.z.z
where z.z.z.z is the address of your name server. The output is similar to the following:
Try typing:
#netstat -nr
This should show three routes similar to the following:
If your output looks similar but does not have the “destination 0.0.0.0” line (which refers to the
default route used for connections), you may have run pppd without the defaultroute option. At
this point, you can try using Telnet, ftp, or finger, bearing in mind that you will have to use
numeric IP addresses unless you have configured /etc/resolv.conf correctly.
MOXA:~# ping 129.67.1.165
PING 129.67.1.165 (129.67.1.165): 56 data bytes
64 bytes from 129.67.1.165: icmp_seq=0 ttl=225 time=268 ms
64 bytes from 129.67.1.165: icmp_seq=1 ttl=225 time=247 ms
64 bytes from 129.67.1.165: icmp_seq=2 ttl=225 time=266 ms
^C
--- 129.67.1.165 ping statistics ---
3 packets transmitted, 3 packets received, 0% packet loss
round-trip min/avg/max = 247/260/268 ms
MOXA:~#
Kernel routing table
Destination Gateway Genmask Flags Metric Ref Use
iface
129.67.1.165 0.0.0.0 255.255.255.255 UH 0 0 6
ppp0
127.0.0.0 0.0.0.0 255.0.0.0 U 0 0 0 lo
0.0.0.0 129.67.1.165 0.0.0.0 UG 0 0 6298
ppp0
