V2401/2402 Series Linux User’s Manual Managing Communications
3-23
ATTENTION
If you hope to have auto dial-in service, you can respawn the dial-in service in /etc/inittab.
PPPoE
The following procedure is for setting up PPPoE:
1. Connect the V2401/2402-LX’s LAN port to an ADSL modem with a cross-over cable, HUB,
or switch.
2. Log in to the V2401/2402-LX as the root user.
3. Edit the file /etc/ppp/chap-secrets and add the following:
“username@hinet.net” * “password” *
username@hinet.net is the username obtained from the ISP to log in to the ISP account.
password is the corresponding password for the account.
MOXA:~# mount –o remount,rw /dev/sda1/
MOXA:~# echo “p0:2345:respawn:pppd call dialin” >>
/etc/inittab
MOXA:~# umount /
# Secrets for authentication using CHAP
# client server secret IP addresses
# PPPOE example, if you want to use it, you need to unmark it
and modify it
"username@hinet.net" * "password" *
