DA-662A Series Software Getting Started
2-12
104 root 4044 S /usr/sbin/snmpd –s –l /dev/null
106 root 2832 S /usr/sbin/snmptrapd -s
135 root 1364 S /sbin/cardmgr
139 root 1756 S /usr/sbin/rpc.nfsd
141 root 1780 S /usr/sbin/rpc.mountd
148 root 2960 S /usr/sbin/sshd
156 root 1272 S /bin/reportip
157 root 1532 S /sbin/getty 115200 ttyS0
158 root 1532 S /sbin/getty 115200 ttyS1
162 root 3652 S /usr/sbin/sshd
163 root 2208 S -bash
169 root 2192 S ftpd: 192.168.3.110: root: IDLE
187 root 1264 S ./tcps2-release
188 root 1592 S ps
root@Moxa:~#
NOTE
Use the kill -9 command for PID 187 to terminate this program: #kill -9 187
Testing Procedure Summary
1. Compile tcps2.c (#make).
2. Upload and run tcps2-release in the background (#./tcps2-release &).
3. Check that the process is running (#ps).
4. Use a serial cable to connect PC1 to the DA-662A series‘ serial port 1.
5. Use an Ethernet cable to connect PC2 to the DA-662A series.
6. On PC1: If running Windows, use HyperTerminal (38400, n, 8, 1) to open COMn.
7. On PC2: Type #telnet 192.168.3.127 4001.
8. On PC1: Type some text on the keyboard and then press Enter.
9. On PC2: The text you typed on PC1 will appear on PC2‘s screen.
The testing environment is illustrated in the following figure. However, note that there are limitations to the
example program tcps2.c.
