DA-662A Series Software Managing Embedded Linux
3-6
Next, use vi editor to open your application program. We use the example program tcps2-release, and allow
it to run in the background.
192.168.3.127 - PuTTY
# !/bin/sh
# Add you want to run daemon
/root/tcps2-release &
After rebooting the system, the following daemons will be enabled.
192.168.3.127 - PuTTY
PID USER VSZ STAT COMMAND
1 root 1632 S init [3]
2 root 0 SW [kthreadd]
3 root 0 SW [ksoftirqd/0]
4 root 0 SW [kworker/0:0]
5 root 0 SW [kworker/u:0]
6 root 0 SW [rcu_kthread]
7 root 0 SW< [khelper]
8 root 0 SW [kworker/u:1]
155 root 0 SW [sync_supers]
157 root 0 SW [bdi-default]
158 root 0 SW< [kintegrityd]
160 root 0 SW< [kblockd]
169 root 0 SW [khubd]
186 root 0 SW< [rpciod]
188 root 0 SW [kworker/0:1]
194 root 0 SW [kswapd0]
195 root 0 SW [fsnotify_mark]
196 root 0 SW< [aio]
197 root 0 SW< [nfsiod]
198 root 0 SW< [crypto]
212 root 0 SW [ocf_0]
213 root 0 SW [ocf_ret_0]
535 root 0 SW [swapper]
536 root 0 SW [swapper]
537 root 0 SW [swapper]
538 root 0 SW< [scsi_tgtd]
548 root 0 SW [mtdblock0]
553 root 0 SW [mtdblock1]
558 root 0 SW [mtdblock2]
563 root 0 SW [mtdblock3]
790 root 0 SW [scsi_eh_0]
791 root 0 SW [usb-storage]
839 root 0 SWN [jffs2_gcd_mtd3]
866 root 1696 S /bin/inetd
871 bin 1616 S /bin/portmap
875 root 2708 S /bin/sh --login
883 root 1680 S /bin/snmpd
913 root 4092 S /bin/sshd -6 -f /etc/ssh/sshd_config
917 root 4092 S /bin/sshd -4 -f /etc/ssh/sshd_config
923 root 1968 S /usr/bin/in.tftpd -cpls /home/tftpboot
937 root 1488 S /bin/lcmshowinfo
939 root 1620 S /bin/cron
944 root 2096 S pure-ftpd (SERVER)
1055 root 2712 S -bash
