DA-662A Series Software Managing Embedded Linux
3-2
System Version Information
To determine the hardware capability of your DA-662A series, and what kind of software functions are
supported, check the version numbers of your DA-662A series‘ firmware version. Contact Moxa to determine
the hardware version. You will need the Production S/N (Serial number), which is located on the DA-662A
series‘ bottom label. To check the kernel version, type:
#kversion
192.168.3.127 - PuTTY
root@Moxa:~# kversion
DA-662A-16-LX version 1.0
root@Moxa:~#
Upgrading the Firmware
The DA-662A series‘ BIOS, kernel, and user file system are combined into one firmware file, which can be
Moxa‘s website (www.moxa.com). The name of the file has the form
FWR_DA662A_Vx.x_Build_YYMMDDHH.hfm, with ―x.x.x‖ indicating the firmware version. To upgrade the
firmware, download the firmware file to a PC, and then transfer the file to the DA-662A series unit via a serial
Console or Telnet Console connection.
ATTENTION
Upgrading the firmware will erase all data on the Flash ROM
If you are using the ramdisk to store code for your applications, beware that updating the firmware will erase
all of the data on the Flash ROM. You should back up your application files and data before updating the
firmware.
Since different Flash disks have different sizes, it‘s a good idea to check the size of your Flash disk before
upgrading the firmware, or before using the disk to store your application and data files. Use the #df –h
command to list the size of each memory block, and how much free space is available in each block.
192.168.3.127 - PuTTY
root@Moxa:/# df –h
Filesystem Size Used Available Use% Mounted on
/dev/root 12.0M 9.2M 2.8M 77% /
devtmpfs 61.0M 0 61.0M 0% /dev
/dev/ram0 1003.0K 22.0K 930.0K 2% /var
/dev/cfa1 1.6G 1021.8M 509.9M 67% /var/cf
/dev/mtdblock3 16.0M 860.0K 15.2M 5% /tmp
/dev/mtdblock3 16.0M 860.0K 15.2M 5% /home
/dev/mtdblock3 16.0M 860.0K 15.2M 5% /etc
root@Moxa:/# upramdisk
root@Moxa:/# df -h
Filesystem Size Used Available Use% Mounted on
/dev/root 12.0M 9.2M 2.8M 77% /
devtmpfs 61.0M 0 61.0M 0% /dev
/dev/ram0 1003.0K 23.0K 929.0K 2% /var
/dev/cfa1 1.6G 1021.8M 509.9M 67% /var/cf
/dev/mtdblock3 16.0M 860.0K 15.2M 5% /tmp
/dev/mtdblock3 16.0M 860.0K 15.2M 5% /home
/dev/mtdblock3 16.0M 860.0K 15.2M 5% /etc
/dev/ram1 15.5M 128.0K 14.6M 1% /var/ramdisk
root@Moxa:/# cd /mnt/ramdisk/
root@Moxa:/mnt/ramdisk#
