Moxa DA-662A-16-LX [21/63] Da 662a series software getting started

DA-662A Series Software Getting Started

2-13

NOTE

The tcps2.c application is a simple example designed to give users a basic understanding of the concepts

involved in combining Ethernet communication and serial port communication. However, the example program

has some limitations that make it unsuitable for real-life applications.

1. The serial port is in canonical mode and block mode, making it impossible to send data from the Ethernet

side to the serial side (i.e., from PC 2 to PC 1 in the above example).

2. The Ethernet side will not accept multiple connections.
