IA240/241 Linux User’s Manual Managing Embedded Linux
3-2
System Version Information
To determine the hardware capability of your IA240/241, and what kind of software functions are
supported, check the version numbers of your IA240/241’s hardware, kernel, and user file system.
Contact Moxa to determine the hardware version. You will need the Production S/N (Serial
number), which is located on the IA240/241’s bottom label.
To check the kernel version, type:
#kversion
192.168.3.127 – PuTTY
root@Moxa:~# kversion
Version 1.0
root@Moxa:~#
NOTE The kernel version number is for the factory default configuration, and if you download the latest
firmware version from Moxa’s website and then upgrade the IA240/241’s hardware.
System Image Backup
Upgrading the Firmware
The IA240/241’s bios, kernel, and root file system are combined into one firmware file, which can
be downloaded from Moxa’s website (www.moxa.com
). The name of the file has the form
ia240-x.x.x.frm or ia241-x.x.x.frm, with “x.x.x” indicating the firmware version. To upgrade the
firmware, download the firmware file to a PC, and then transfer the file to the IA240/241 via a
serial Console or Telnet Console connection.
ATTENTION
Upgrading the firmware will erase all data on the Flash ROM
If you are using the ramdisk to store code for your applications, beware that updating the
firmware will erase all of the data on the Flash ROM. You should back up your application files
and data before updating the firmware.
