IA240/241 Linux User’s Manual Managing Embedded Linux
3-4
ftp> get ia240-1.0.frm
local: ia240-1.0.frm remote: ia240-1.0.frm
200 Port command successful.
150 Opening data connection for ia240-1.0.frm
226 Transfer complete.
13167772 bytes received in 2.17 secs (5925.8 kB/s)
ftp>
3. Next, use the upfirm command to upgrade the kernel and root file system:
#upfirm ia240-x.x.x.frm
192.168.3.127 – PuTTY
root@Moxa:/mnt/ramdisk# upfirm ia240-1.0.frm
Moxa IA240 upgrade firmware utility version 1.0.
To check source firmware file context.
The source firmware file conext is OK.
This step will destroy all your firmware.
Continue ? (Y/N) : Y
Now upgrade the file [kernel].
Format MTD device [/dev/mtd1] . . .
MTD device [/dev/mtd1] erase 128 Kibyte @ 1C0000 – 100% complete.
Wait to write file . . .
Compleleted 100%
Now upgrade the file [usrdisk].
Format MTD device [/dev/mtd2] . . .
MTD device [/dev/mtd2] erase 128 Kibyte @ 800000 – 100% complete.
Wait to write file . . .
Compleleted 100%
Upgrade the firmware is OK.
ATTENTION
The upfirm utility will reboot your target after the upgrade is OK.
Loading Factory Defaults
To load the the factory default settings, you must press the reset-to-default button for more than 5
seconds. All files in the /home & /etc directories will be destroyed. Note that while pressing the
reset-to-default button, the Ready LED will blink once every second for the first 5 seconds. The
Ready LED will turn off after 5 seconds, and the factory defaults will be loaded.
