IA3341 Hardware User's Manual Hardware Connection Description
3-6
3. Be sure to insert the SD card correctly into the protective cover, as shown in the figure below. Push inward
and make sure that the SD card has been completely plugged in.
4. When finished, use screws to attach the protective cover to the computer.
ATTENTION
The IA3341 does not support SD hot swap and PnP (Plug and Play) function. It is necessary to remove power
source first before inserting or removing the SD card.
USB Hosts
The IA3341 provides 1 USB 2.0 full speed host (OHCI), type A connectors, which supports a keyboard or mouse,
as well as an external flash disk for storing large amounts of data.
