System setup

Operation

1. Turn on the power switch located at the rear side of subwoofer, the system implies a

standby mode.

2. Press STANDBY to excite system while red light will shine indicating a working

mode. Press button one more time and system STANDBY and system shift to

standby mode.

3. Switch to the input selection you want (DVD/INPUT/MP3/TUNER) and choose sound

mode you prefer (5.1, 2.1, 3.1, DSP), then playing from the source should begin.

4. VOL+/VOL- : press it to increase or decrease main volume.

5. You can attune your musical surround by adjusting volume of subwoofer (SUB +/-),

central speaker (CENT+/-) and rear speakers (SL +/-, SR +/-).

6. Also you can change tunings for BASS and TREBLE (BASS +/-, TREBLE +/-)

Tuner Operation (optional)

1. Press the TUNER button, the unit will be switched to tuner mode. Now the tuner is

in FM band, the LCD panel will display FM icon and the original frequency 87 MHZ.

2. Search for broadcasting channel. The button TUNER▼/▲ is used for searching

backward or forward. When the button is pressed for over one second, Auto-

searching mode is activated and the variable frequency will be displayed at the

same time.

3. Store or select the station frequency. You may store a radio channel in one of the

number buttons by pressing the button MEM at first and then press the

corresponding number button which you want to store in. You may select the radio

channel by directly pressing the button with marks 1, 2, 3, 4, etc. The corresponding

frequency will be displayed on the LCD panel.
